composition: special synthetic rubber, modified resin, curing agent
recommend: the paint is widely applied to the surface of he light metal and concrete, rail bridge, high voltage transmission tower, container, the equipment of offshore drilling and production, chassis, heavy machinery, ship ,chemical, pipeline and gas tank.
characteristic: the paint is hard to burn and self extinguish. the salt spray resistance and humidity resistance of the paint last more than 7 days.
basic data: colour all colours
mixing ratio main agent/curing agent=100/10（weight ratio）
solid content 23%
specific gravity 1.27
paint thick film dry film: 15~25um/layer wet film: 60~80um/layer
theoretical ＆#118alue: 7.9square meters/litre/15um
actural ＆#118alue: it is related to the surface treatment, invironment and way of construction.
storage: storage temperature 10℃~40℃
storage period a year
flash point above23℃
construction data: mixed using period temperature（℃） 5 10 20 30
mixed using period（h） 30 20 10 8
way of paint: spraying, brush painting, roller coating
spraying pressure 0.3~0.6mpa
dilution ratio 0~10%（volume ratio）
diluent special diluent
construction temperature 10℃~50℃
drying time& temperature（℃） 5 10 20 30
interval of the painting dry finger touch（min） 60 45 30 15
min interval of the painting（h） 24 24 24 16
max interval of the painting（day） 7 7 7 7
matching metal: steel
lower paint th 77stable epoxy rust primer
tj52 11 chlorosulfonated polyethylene primer(split charging)
tj52 12 chlorosulfonated polyethylene intermediate coat paint(split charging)
surface treatment: wash away the water soluble dirt and the salt. degrease according to the cleaning standards of sspc—sp1 solvent. remove the rust and the oxcide scale by sand blasting so that it can reach the standard of isosa2.5 ( sspc—sp10 ) or higher standard.
safety measure: keep the paint away from the eyes and skin. if you touch the paint, you can wash your hands by warm water or cleaning agent. if the paint hurt your eyes, you should wash your eyes with water and go to see the doctor immediately. keep the room well ventilated. there are conbustible materials in the paint. please keep it away from fire and don’t smoke nearby. the safety rule must be obeyed.
|
